FG Barra/Territory

FG Barra/Territory

$1,779.00 AUD
$1,779.00 AUD
Sale Sold out

All Mamba turbo chargers are balanced by award winning SCHENCK balancing machinery.

  • Ford Falcon XR6 Barra 4.0L FG, G6E, Territory
  • Direct bolt on housing

        GTX3576RS 3" A/R .50 + 1.05

  • Compressor wheel: 59/76.1mm/Trim 60 (7+7 Blade Performance Billet Compressor Wheel)
  • Turbine Wheel: 62/68 (9 Blade high flow)
  • Compressor Housing: 3” Cover Inlet, 2” Outlet, A/R .50 T04E Type.
  • Turbine Housing: A/R. 1.05, T3 Flange, 5 Bolt Turbine Outlet (Fits factory Barra Dump pipe)

        GTX3582R 3" A/R .50 + 1.05

  • Compressor wheel: 62.5/82.5mm (7+7 Blade Performance Billet Compressor Wheel)
  • Turbine Wheel: 62/68 (9 Blade high flow)
  • Compressor Housing: 3” Inlet, 2” Outlet, A/R .50 T04E Type.
  • Turbine Housing: A/R .1.05, T3 Flange, 5 Bolt Turbine Outlet (Fits factory Barra Dump pipe)

        GTX3576R 4" A/R .70 + .82

  • Supports 450-750HP
  • Comp. Wheel: 59 / 76.1 mm / Trim 60 (GTX 11+0 Blade Billet Wheel w/ Extended Tip)
  • Turbine Wheel: 62 mm / 68 mm / Trim 84 (GT35R)
  • Compressor Housing: 4" Inlet, 2.5” Outlet, A/R .70
  • Turbine Housing A/R .82, T3 Flange, 5 Bolt Turbine Outlet (Fits factory Barra Dump pipe)

        GTX3582R 4" A/R .70 + .63

  • Supports 500-650HP
  • Comp. Wheel: 62.5 / 82.5 mm / Trim 58 (GTX 11+0 Blade Billet Wheel w/ Extended Tip)
  • Turbine Wheel: 62 mm / 68 mm / Trim 84 (GT35R)
  • Compressor Housing 4” Inlet, 2.5" Outlet, A/R .70
  • Turbine Housing A/R .63, T3 Flange, 5 Bolt Turbine Outlet (Fits factory Barra Dump pipe)

        GTX3582R 4" A/R .70 + .82

  • Supports 500-650HP
  • Comp. Wheel: 62.5 / 82.5 mm / Trim 58 (GTX 11+0 Blade Billet Wheel w/ Extended Tip)
  • Turbine Wheel: 62 mm / 68 mm / Trim 84 (GT35R)
  • Compressor Housing 4” Inlet, 2.5" Outlet, A/R .70
  • Turbine Housing A/R .82, T3 Flange, 5 Bolt Turbine Outlet (Fits factory Barra Dump pipe)

        GTX3584R 4" A/R .70 + .82

  • Supports 550-1000HP
  • Comp. Wheel: 66.3 /84 mm (GTX T04Z 11+0 Blade Billet Wheel w/ Extended Tip)
  • Turbine Wheel: 62 mm / 68 mm / Trim 84 (GT35R)
  • Compressor Housing 4” Inlet, 2.5" Outlet, A/R .70
  • Turbine Housing A/R .82, T3 Flange, 5 Bolt Turbine Outlet (Fits factory Barra Dump pipe)

        GTX3584R 4" A/R .70 + 1.05

  • Supports 550-1000HP
  • Comp. Wheel: 67/84 mm/Trim 64 (GTX T04Z 11+0 Blade Billet Wheel w/ Extended Tip)
  • Turbine Wheel: 62 mm / 68 mm / Trim 84 (GT35R)
  • Compressor Housing 4” Inlet, 2.5" Outlet, A/R .70
  • Turbine Housing A/R. 1.05, T3 Flange, 5 Bolt Turbine Outlet (Fits factory Barra Dump pipe)

        All Turbos Include:

  • Ceramic Dual Ball Bearing
  • Oil & water-cooled
  • Fitting Kit
  • 0.8bar spring pre-installed.
  • Additional 1.2bar and 1.5bar springs included
